SB 70 Glass for Custom Steel Windows & Doors
What Is SB70 Glass?
SB 70 pairs a low solar heat gain coefficient (SHGC) with high visible light transmission (VT). That combination is what distinguishes it from many solar control products, which typically reduce heat gain at the cost of daylight: SB 70 reduces heat gain while keeping the glass close to the brightness and clarity of clear glass.
SB 70 has a neutral, color-true appearance from both the interior and exterior, without the reflective mirror effect some solar control coatings produce, and without a green or blue tint.
SB 70 is specified for large glazing areas, curtain wall applications, and facades with heavy solar exposure, where maximizing daylight without overheating the interior is a project priority. For floor-to-ceiling steel fenestration with substantial glass area, it's the standard upgrade specification.
The following are confirmed NFRC values for specific Studio Steel fixed-window configurations. Values vary by product type and pane configuration; confirm project-specific data with the Studio Steel team or the NFRC data page.
| Configuration | U-Factor | SHGC |
|---|---|---|
| Dual pane w/ laminate, fixed window | 0.30 | 0.22 |
| Triple pane (SB70/SB70/Clear), fixed window | 0.21 | 0.15 |
SB 70 can be incorporated into double pane, triple pane, tempered, and laminated glass builds.
